8-Port Combo KVM Switch

» KVM-210-08

Easily Control Servers with Flexibility
PLANET offers an ideal enterprise 8-port KVM switch solution for company server room or testing facilities. The KVM-210-08 8-port Combo KVM Switch features the patented design of the availability of USB and PS/2 interface connection, user-friendly OSD utility and daisy-chain function. The KVM switch solution frees up more table and rack space for users in addition to saving the cost of multiple keyboards, mice and monitors.

Computer Switching
There are three convenient methods to access any computer connected to the installation:

  • Port select button
  • Hotkeys on keyboard
  • OSD (on screen display)

Flexible LED Display
You could check the computer status on the front LED of the KVM-210-08. “Red” indicates that a computer is connected to the corresponding port and “Green” indicates that the computer connected to the corresponding port has focus.

Two Level Password Security Protection
Two level password security only authorizes up to one user and an administrator with a separate profile for each user.

Easy to Install
Simply plug cables into their appropriate ports. There is no software to configure, and no incompatible problems. It works on multiple operating platforms like Windows, Linux, Mac, Sun, etc.

Powerful Mouse/Keyboard Support
In the present computer applications, a mouse has become an indispensable device. The KVM-210-08 fully supports all models of PS/2 mice on the market. The KVM also supports the PS/2 keyboard port of code set 1/2/3 and further allows you to use the KVM for all kinds of servers, computers or their combination.

Standalone Operation
The KVM-210-08 allows access and controls up to 8 computers from a single console (Keyboard, mouse and monitor).

Cascade Operation
By cascading to 8 KVM switches, it can control up to 64 servers.

Hardware

  • 1U rack-mount size and desktop design
  • Standalone machine controls up to 8 sets of computers
  • Up to 2 levels can be cascaded and up to 64 computers can be controlled
  • Front panel status LEDs give a clear indication of the active computers
  • Supports a high resolution of up to 2048 x 1536 and 350MHz of bandwidth

Security
  • Two-layer password security protection

Management
  • Auto scan mode for monitoring computers
  • Requires no additional software or hardware
  • Computer selection via Port Select Button, Hotkey and On Screen Display (OSD)
  • Hot pluggable: Add or remove computers without having to power down the switch
  • QVS (Quick View Setting): Quickly select your computer by naming or SN number

Compatibility
  • Multiplatform support -- Windows, Linux and Sun
  • Supports Microsoft Intellimouse, Logitech Net Mouse and all other third party’s PS/2 mice
Hardware
Number of Ports8
Maximum64 by cascading (KVM-210-08 x 8)
PC Ports
Keyboard:PS/2 female + USB Type A female
Mouse:PS/2 female + USB Type A female
Video:8 x HDB-15 female
Console Ports
Keyboard:PS/2 female + USB Type A female
Mouse:PS/2 female + USB Type A female
Video:1 x HDB-15 female
LED
On Line:8
Selected:8
Button
Reset:1
Select:8
Video Resolution2048 x 1536
HousingMetal
Dimensions (W x D x H)432 x 155 x 44 mm
Weight2.22kg
Power Requirement9V DC, 1A
Installation1U rack-mountable, desktop
Management
PC SelectionPort select button
Hotkeys on keyboard
OSD (on screen display)
Scan Interval5~60 seconds
SecurityUser password and super password
Environment & Certification
Operating Temperature-10 ~ 50 degrees C
Operating Humidity0 ~ 90%
RegulatoryCE, FCC
DateVersionDescriptionDownload
2017/06/011.0

KVM-210-08

 Download Icon
DateVersionDescriptionDownload
2016/17/101.0

Initial Release

 Download Icon
DateVersionDescriptionDownload
2017/12/011.0

Initial Release

 Download Icon


Model

Description

KVM-210-16

16-Port Combo KVM Switch

Ordering Information

KVM-210-08

8-Port Combo KVM Switch

Ordering Information

KVM-210-08

8-Port Combo KVM Switch
Accessories

KVM-KC1-1.8

1.8M USB KVM Cable with built-in PS2 to USB Converter

KVM-KC1-3

3M USB KVM Cable with built-in PS2 to USB Converter

KVM-KC1-5

5M USB KVM Cable with built-in PS2 to USB Converter
